Defi-Monitor

Model: MEA35-50D

DESCRIPTION:

• Defibrillator with built-in Vital Function Monitor
• 12-lead ECG monitoring
• 8.4 ”TFT screen, with a resolution of 800 × 600 pixels
• Energy released: 1,2,3,4,5,6,7,8,9,10,15,20,30,40,50,75,100,125, 175,200,300,360 J
• Charging time for 200 J of 6 seconds, 9 seconds for 360 J Adult / pediatric paddle defibrillation
• Advanced biphasic technology
• Manual and automatic AED operation
• Button control: Key (Stop, AED, Manual, Pacing and Monitor); 11 buttons (Shock, Energy level selection, Charging, Analysis, NIBP, Derivatives, Alarm, Size, Listing, 5 soft keys
• Non-invasive pacemaker, stimulation mode: on request
• Stimulation rate: 30-180 ppm
• Resolution: 2 ppm
• Precizie: ± 5% or 5 mA
• Ritm cardiac – Interval de masusrare:0,2-300 bpm
• Precizie: ± 5 bpm

ECG

• 3/ 5/12 derivatii
• Derivatii: I, II, III, aVR, aVL, V1, V3, V4, V5, V6, Padele, Pad-uri
• Detectarea derivatiilor si afisarea lor pe ecran

NIBP

• Rata de puls (adult/pediatric): 40-200 bpm
• Neonatal: 40-240 bpm
• Rezolutie: 5 bpm
• Precizie: ± 2 bpm

SpO2

• Interval de masurare: 1-100 %
• Intervalul ratei de puls 20-300 bpm
• Interval perfuzie: 0,03-20 %
• Viteza de afisare: 25 mm/s
• Alarma: Categorii (Status pacient si Status sistem); Prioritati (Scazut, Mediu si Ridicat); Notificari vizuale si audio; Ajustari implicit si individual; Nivelul volumului intre 45 si 85 dB
• Imprimanta termica cu latime de 80 mm si viteza de 25 mm/s
• Tensiune de alimentare: 100-240 V, 50-60 Hz
• Temperatura de operare: 0-50° C
• Umiditate fara condensare: 15-95%
• 14.4 V / 6600 mAh Li-ion battery, enough for 200 shocks at 200 joules
• Weight: with battery and without paddles and accessories:  6.2 kg

Optional:

• SpO2
• 12-channel ECG
• NIBP / Temp
• IBP

Dimensions: 340 W x 305 H x 210 D mm
